SIGNIFY Gardco Form Ten Series Installation Manual page 20

REQUIRED TOOLS: 11/32" SOCKET/OPEN-END WRENCH
READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING THIS
FIXTURE.
CAUTION: THE ELECTRICAL POWER MUST BE DISCONNECTED BEFORE
OPENING THE FIXTURE. FAILURE TO FOLLOW THE INSTALLATION
DOCUMENTATION OR OPERATING THIS PRODUCT OTHERWISE, THEN FOR
ITS INTENDED USE VOIDS THE WARRANTY.
STEP 1:
Insert Mounting Brackets (2X Back) into the back slots.
STEP 2:
Remove the paper liner of the double-sided tape on the bird
spikes.
STEP 3:
Carefully place the bird spikes on the housing. Make sure to align
the holes with the screw.
STEP 4:
Insert Mounting Brackets (2X Front) into the front slots.
STEP 5:
Carefully place the bird spikes on the housing. Make sure to align
the holes with the screw. Screw locknuts onto self-clinching
threaded studs (4x).
NOTE: If necessary, trim any additional lengths of spikes that
overhang the luminaire
page 2
BIRD DETERRENT
443560818880 Rev C
