SILICONE RUBBER
LAMP HOLDER
(DOUILLE EN
GOMME SILICONIQUE)
UPLIGHT
ECLAIRAGE VERS LE HAUT
This fixture is intended for installation in accordance with the National Electrical Code and local code
specifications. Failure to adhere to these codes and instructions may result in serious injury and/or damage
to the ballast and void the warranty. These instructions do not purport to cover all details or variations in
equipment, nor to provide for every possible contingency related to installation, operation, maintenance,
or mounting situation. Should specific problems occur that are not addressed by these instructions, contact
your Sales Representative or distributor for assistance. Retain these instructions for future reference.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO PERSONS-IMPORTANT SAFETY INSTRUCTIONS
Lighted lamp is HOT! WARNING- To reduce the risk of FIRE OR INJURY TO PERSONS: Turn off/unplug and
allow to cool before replacing lamp. Lamp gets HOT quickly! Contact only switch/plug when turning on.
Do not touch hot lens, guard, or enclosure (see diagram/picture). Keep lamp away from materials that
may burn. Do not touch the lamp at any time. Use a soft cloth. Oil from skin may damage lamp. Do not
operate the luminaire fitting with a missing or damaged shield. SAVE THESE INSTRUCTIONS.
Xenon lamps do not require additional shielding.
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: 855-486-2216
32000624, revision J
SPADE TERMINALS
(BORNE EMBROCHABLE)
6"-12" EXTRA WIRE
(6"-12" FIL SUPPLEMENTAIRE)
PVC HOUSING
(BOITIER DE PVC)
48" 18-2 LOW VOLTAGE
WIRE WITH QUICK CONNECT
(48" 18-2 FIL A BASSE
TENSION AVEC CONNECTEUR
A CONNEXION RAPIDE)
Signify Canada Ldt./ Signify Canada Ltée
281 Hillmount Road
Markham ON, Canada L6C 2S3
Phone: 800-668-9008
INSTALLATION INSTRUCTIONS:
12V INGROUND WELL LIGHT
3"
SPOTLIGHT
PROJECTEUR
3"
3"
GRANULAR
MATERIAL
(MATERIAU
GRANULEUX)
