Anybus Wireless Bolt LTE
11.1.4. IP Address
Command: ip
Returns:
• cellular_ip
• cellular_gateway
• eth0_ip
• eth0_mask
Example 15. Get the Bolt LTE IP addresses
Message to Bolt LTE:
my_access_code ip
Reply message from Bolt LTE:
cellular_ip: 100.12.345.67
cellular_gateway: 100.12.345.68
eth0_ip: 123.45.678.9.11
eth0_mask: 255.255.255.0
11.1.5. MAC Address
Command: mac
Returns: The Bolt LTE MAC (Media Access Control) address.
Example 16. Get the Bolt LTE MAC address
Message to Bolt LTE:
my_access_code mac
Reply message from Bolt LTE:
MAC: 00:00:5E:00:53:AF
