Anybus Wireless Bolt LTE
5.11. Setting Up with REST Commands
How To Use REST Commands
For information about the supported REST commands and how to use them, refer to the REST Commands
Reference Guide at www.anybus.com/support.
Use/Test REST Commands From a Web Browser
For information about the supported REST commands, refer to the REST Commands Reference Guide at
www.anybus.com/support.
Procedure
1. Setup the Bolt LTE as an internet router.
Refer to Set Up Bolt LTE as an Internet Router (page 36)
To send the REST command to the Bolt LTE:
2. Connect the Bolt LTE to your PC and log in to the Bolt LTE built-in web interface.
3. Open a new tab in your web browser.
4. Enter the desired command string in the Address bar.
5. To send the string, press Enter.
Result
• The command is sent to the TCP port 80 on the Bolt LTE Ethernet interface.
• The Bolt LTE enters the state requested by the REST command.
Example 5. URL
http://192.168.0.99/cgi-bin/info.cgi
Example 6. Response
{"uptime":"338053","time":"1980-01-11 02:24:04",
"radio_power":"1","sim":"2","signal_strength":"4",
"signal_strength_raw":"22","signal_quality":"-10",
"cell_id":"26650646",""operator":"Telavox","status":"1",
"amplifier_temp":"31","controller_temp":"31","connection_state":"2",
"voltage":"3868","iotbolt_version":"1.00.50-dev",
"modem_version":"SWI9X06Y_02.16.06.00","pri":"GENERIC_001.028_004",
"apn":"online.telia.se","rat_specific":"7","imsi":"240017431192642",
"imei":"352653090225053","cellular_gateway":"10.209.230.108",
"cellular_ip":"10.209.230.107","iccid":"89460100174311926424"}
