Ethernet Settings
5.6. Ethernet Settings
IP Settings
Figure 12. Ethernet Settings page, default IP Settings with Internal DHCP Server Enabled
To Change the Bolt LTE IP Address
NOTE
The default Bolt LTE static IP address is 192.168.0.98.
Procedure
1. In the IP Address field, enter the new IP address.
2. For the setting to take effect, click Save and Reboot.
The Bolt LTE reboots.
3. You may need to reconfigure your PC to match the new Bolt LTE IP address. See
(page 14).
4. In your web browser, enter the new IP address and press Enter.
The Bolt LTE built-in web interface login screen appears.
5. Enter Username and Password and click Sign in.
Subnet Mask
NOTE
The default subnet mask is 255.255.255.0. The subnet mask identifies the subnetwork to which the
static IP address belongs.
Internal DHCP Server
IMPORTANT
By default, the Bolt LTE internal DHCP server is enabled. To avoid interference, keep only one DHCP
server enabled on the network.
NOTE
The DHCP server is only enabled on the LAN interface.
By default, Internal DHCP Server is set to Enabled.
This means that the IP address settings are set automatically by the Bolt LTE internal DHCP server.
