Set Up Bolt LTE as an Internet Router
Verify Internet Connection
Bolt LTE should now be connected to internet.
NOTE
Depending on the mobile network operator and network type, it can take up to 10 minutes the first
time Bolt LTE is connecting to internet.
Verify that Bolt LTE is connected to internet, by sending a ping to Google Public DNS.
1. On the Diagnostics page, select the Ping method.
2. In the Target field, enter the IP address 8.8.8.8.
3. To Perform Action, click Start.
The ping request is sent. When the ping response return, a message appears.
Figure 29. Example, Ping response message from Target 8.8.8.8
To Do Next
Connect Devices
Figure 30. Connect a device to internet
To connect a device to internet:
1. Connect an Ethernet cable between Bolt LTE and the device.
2. Verify that the device is connected to internet.
