Anybus Wireless Bolt LTE
4.3. Connect to Power Over Ethernet (PoE)
Before You Begin
IMPORTANT
Connecting the Bolt LTE to PoE and DC power simultaneously may result in a current loop that could
damage both the power sources and the Bolt LTE. Ensure to use only one of the power connections
at a time.
NOTE
Both shielded and unshielded Ethernet cables may be used.
NOTE
Bolt LTE is designed to comply with PoE, IEEE 802.3at Type 1 (Class 0, 37-57 VDC, max 12.95 W).
Procedure
Figure 3. Connect to Power Over Ethernet (PoE)
Connect the Bolt LTE Ethernet port to Ethernet/PoE.
Page 8 of 62
Connect to Power Over Ethernet (PoE)
SCM-1202-164 Version 1.5
