Connect to Power and Ethernet
Procedure
Connect to power and Functional Earth (FE)
Figure 5. Power and Functional Earth (FE)
1.
Connect Bolt LTE Power connector to a power supply.
2.
Connect Bolt LTE Power connector to Functional Earth (FE).
Table 2. Power connector, 3-pin terminal block
Pin
1
2
3
SCM-1202-164 Version 1.5
Function
+
-
Functional Earth (FE)
®
Anybus
Wireless Bolt LTE
11-33 VDC
Page 11 of 62
™
