1-22 Technical Information

SPECIFICATIONS

Table Section 1-7 provides a complete list of NEC Versa series system specifications.
Item
Chassis Configuration
Size
Keyboard
Device Slots
Power
Battery Pack
Li-Ion
NiMH
Table Section 1-7 Specifications
Specification
Width: 11.7 in. (303 mm)
Depth: 9.04 in. (229.5 mm)
Height: 2.05-inch (52.0 mm)
Weight: 6.8 to 7.3 lb (3.1 to 3.3 kg), Exact weight depends on
LCD and battery type.
PS/2 compatible, 86-key standard (79-key for UK and
Germany) (includes Fn Key for ROM-based functions)
Two PC Card slots that support up to two optional cards-
oriented one on top of the other
One 3 1/2-inch x 0.75-inch high slot, front access for standard
hard disk drive
Two memory connectors for optional memory DIMM's, located
on the bottom of system.
100 to 240 Vac at 50 or 60 Hz
Output Voltage — 15 V DC, 1.8 A and 18V 1A)
Weight .88 lb (400 Kg)
Voltage 14.4 V
Capacity 2700 mAH
Battery Life Approximately 1hr 40min to 3 hours (depending
on model and power management settings)
Recharging Time
on or off
Bridge Battery Backs up memory contents up to 1 hour with
a fully charged battery in Suspend mode
Weight 1.32 lb (400 Kg)
Voltage 9.6V
Capacity 3500 mAH
Battery Life Approximately 2 hours to 4 hours (depending on
model and power management settings)
Recharging Time
on or off
Approximately 3 hours when the system is
Approximately 3 hours when the system is
