1-6
Technical Information
CD-ROM Reader and Diskette Drive
A 10X CD-ROM reader and 1.44-MB diskette drive come installed in the NEC Versa
2600 Series on the front of the computer.
HARDWARE OVERVIEW—RIGHT SIDE
Review the following section for a description of the hardware on the right side of the NEC
Versa.
VersaGlide
Left
Selection Button
Figure Section 1-4 VersaGlide Location
Figure Section 1-5 Right Side Features
Right
Selection Button
PC Card
Kensington Lock
Slots
Port
