MAINTENANCE: REFRIGERATION PACKAGE ILLUSTRATION (MODEL HMO2653R.5194 ONLY)

Refrigeration Package Configuration

•

Illustration shown is from model HMO2653R.5194.

•

Your particular refrigeration package may have different refrigeration package layout.

•

Wicking material (shown below) is optional.

•

See DRAIN, HOSE AND BRACKET PLACEMENT ILLUSTRATIONS section in this manual for other

refrigeration layouts.

Condenser Coil

Fans & Brackets

Condenser Coils

and Housing

Electrical Box

Overflow Pan

(With Electric

Heater Rod)

Filter Dryer

Wicking Material

(Optional)

Compressor

Sight Glass

Hot Gas

Evaporator

Coils and Pan
