INSTALLATION, CONTINUED - ELECTRICAL CONNECTIONS / EVAPORATOR FAN AREA

Case Rear

Field Wiring Electrical

Connections

10. Electrical Connections (Certain Remote Cases)

Field wiring connection / electrical access location is at

customer-left side of case.

•

Single phase leads are provided.

11. Evaporator Fan Area

•

Illustration below shows front of case with decking

removed.

•

See Preventive Maintenance section in this manual for

guidelines on cleaning this area.

Fan Shroud

Fan Blade

Drain
