Structural Concepts HARMONY HMO5153R User Manual page 21

REAR SLIDING DOOR WITH ADJOINED PERFORATED PLEXIGLAS® PLENUM (MODEL HMO3953R)
Rear Sliding Door With Adjoined Perforated Plexiglas® Plenum
• The perforated plexiglas® plenum is designed to assist the case in proper air flow.
• Two metal adjoiner brackets connect each door to its adjoining perforated Plexiglas® plenum.
• Adjoining Bracket Connects Rear Sliding Doors to perforated Plexiglas® Plenum
• See previous page for instructions on removing perforated plexiglas® plenum (for cleaning, etc.).
• Caution: See cleaning instructions in this manual for specifics on cleaning the plexiglas® plenum. Using
cleaning solutions that are not listed in this manual can mar plexiglas® surface.
• Caution: After cleaning, servicing, etc., carefully replace perforated plexiglas® plenum back into display
case. Avoid scraping or marring the surface.
Sliding Perforated
Plexiglas® Plenum
Metal Adjoining Bracket (Two Brackets Connect
Each Rear Sliding Door To Its Adjoining Plenum)
• Adjoining Bracket Connects Rear Sliding Doors to
Perforated Plexiglas® Plenum
• Design Allows Perforated Plexiglas® Plenum to Slide
Open in Tandem With Each Sliding Door.
21
Rear Sliding Doors
