INSTALLATION, CONTINUED - CONNECTIONS / CONTROLLER / LOCK / MAIN POWER SWITCH
Controller
Main Power Switch
9. Connections/Controller/Lock/Main Power
Switch (Self-Contained Units)
Controller/Ballast box location is at customer rear.
•
See illustration at left.
•
Below illustrations show layout of controller,
ballasts, main power switch, door lock, terminal
block, etc. after removal of controller/ballast box.
Rear Door
Lock
11
Location of
Cord and Plug
in Self-
Contained
Cases
