Structural Concepts HARMONY HMO5153R User Manual page 23

SECURITY GRID INFORMATION - PAGE #2 of 2
2. Securing Security Grid Into Place and Locking
A. After leaning the security grid back against the two security
brackets, slide the (two) padlocks through the security grid and
the security brackets.
B. Securely lock the padlocks (one key fits both padlocks).
3. Removing and Storing Security Grid and Locks
A. Due to weight and size, Security Grid removal requires two (2)
people.
B. Unlock and remove padlocks. Lean security grid forward. Lift
upward and out of baffle airflow slots.
C. Store security grid, padlocks and keys in a secure location to
prevent theft or damage.
End Glass End Panel
Padlock
Note: Both Casters and
Levelers shown for
illustrative purposes only.
Security
Bracket
•
•
Security
Grid
Enlarged View (At Left)
Enlarged View (at left) shows Padlock through
Security Grid and Security Bracket.
One Security Bracket is at each end of Case.
23
NOTE: ILLUSTRATIONS MAY NOT
EXACTLY REFLECT EVERY
PARTICULAR CASE'S FEATURES
