SEAKEEPER CONNECTBOX USER'S MANUAL
PRODUCT CONNECTBOX
SERVICE SCREEN HIDDEN PAGE
By long-pressing the Service screen icon
overrides allow the enclosure to be manually precessed with a stationary flywheel, run the glycol
and seawater pumps, initiate a data log manually, and, on some models, override the latch
mechanism. These overrides are only available when the flywheel RPM is zero on the Service
screen. If flywheel rotation is detected, the overrides will have ‟NA" beside each override.
The latch override is only available when the brake override is activated. The override enables
testing of the latch mechanism disabled when the brake system is overridden.
Seakeeper models, with updated ConnectBox and GCM software, have an internal data logger
capability. The logger function is triggered by an alarm or a user request from the Service screen
override page. The logger's activation will capture Seakeeper CAN traffic, GPS positioning, NMEA
2000 SoG signal (speed over ground), and NMEA battery monitor messages. Each data log
records 70 seconds of Seakeeper CAN data—60 seconds before the initiation and 10 seconds
after initiation. The GCM can store up to 200 CAN data logs for retrieval. Requesting a data log
would be especially helpful when a Seakeeper experiences issues but does not create a
corresponding alarm.
The Seakeeper manuals website
explain how affected users may opt out of allowing their Seakeeper to share this information.
Page 18 of 27
Document # 90769-1
, one accesses the overrides page (Figure 23). The
Figure 23: Overrides screen. Latch override
visible when brake overridden.
contains operation manuals for each model. The manuals
