Seakeeper 7000 Installation Manual

Gyro
Hide thumbs Also See for 7000:

Advertisement

Quick Links

Download this manual
DOCUMENT # 90020, REV 5
MAR 2009
MODEL 7000 GYRO
INSTALLATION MANUAL
P.O. BOX 999
14528 SOUTH SOLOMONS ISLAND ROAD.
SOLOMONS, MARYLAND, 20688, U.S.A
PHONE: 410-326-1590
FAX: 410-326-1199
E-MAIL: customerservice@seakeeper.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seakeeper 7000

Summary of Contents for Seakeeper 7000

  • Page 1 DOCUMENT # 90020, REV 5 MAR 2009 MODEL 7000 GYRO INSTALLATION MANUAL P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: customerservice@seakeeper.com...
  • Page 2 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Contents: Section 1 – Mechanical Installation Section 2 – Electrical Installation Section 3 – Cooling Installation Section 4 – Startup Section 5 – Installation Checklist Section 6 – Drawings P.O.

  • Page 3: Section 1 - Mechanical Installation

    DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Section 1 – Mechanical Installation P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: customerservice@seakeeper.com...
  • Page 4 This document is intended to give details and guidance to a boat builder or equipment installer to install the Seakeeper, Inc. Model 7000 Stabilizing Gyro. The gyro is capable of producing loads up to 23.5 kN (5300 lbs.) on each foundation saddle and careful consideration should be given to foundation design to insure vessel is capable of handling the loads the gyro will impart into the hull.
  • Page 5 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Precautions – • Gyro flywheel is supported by precision bearings, make certain while unpacking and lifting gyro assembly to not drop or impart mechanical shock as damage to bearings could result.
  • Page 6 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 FIGURE 4 – INSTALLED GYRO CLEARANCE CONSIDERATIONS Page 4 of 9...
  • Page 7 . The starboard saddle bond area is 2002 cm Seakeeper has an optional installation jig available, P/N 90012, that is intended to duplicate the gyro foundation geometry in order to check clearances and alignment. The jig will allow the builder / installer to lay-up and adjust the foundation dimensions to create a low-clearance fit between the gyro foundation saddles and the hull structure.
  • Page 8 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Gyro noise has been measured under steady state conditions (no wave load) in Seakeeper's lab and in our 43 ft Viking test boat. The steady state noise is typically in the range of 70-75 dB unweighted.
  • Page 9 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 FIGURE 2 – INSTALLATION JIG Page 7 of 9...
  • Page 10 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Unpacking Crate – 1) Reference Seakeeper Drawing No. 90001, Model 7000 Hardware Scope Of Supply for items that ship with the gyro. 2) Remove electrical components, cables, and misc. items and set aside.
  • Page 11 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 5) Check that the screws that attach forward and aft braces are tight as these maintain foundation alignments during bonding process. 6) Tape off in 4 places the counterbores at each of the four gimbal bearing bolts to keep adhesive out of screw threads as shown in Figure 5.

  • Page 12: Section 2 - Electrical Installation

    DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Section 2 – Electrical Installation P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: service@seakeeper.com...
  • Page 13 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Introduction – This section for electrical installation explains how to mount the electrical equipment and how to connect the electrical cables. Reference Drawings – 90001, Model 7000 Gyro Hardware Scope Of Supply...
  • Page 14 Precautions – • Each item of electrical equipment has specific mounting instructions. These instructions should be followed to insure proper function of the Model 7000 Gyro. ELECTRICAL EQUIPMENT MOUNTING INSTRUCTIONS- 1) MOTOR DRIVE JUNCTION BOX MOUNTING INSTRUCTIONS a. Bulkhead space required: Approx. 19 W x 31 H inches (483 x 787 mm);...
  • Page 15 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 ELECTRICAL EQUIPMENT POWER CONNECTION INSTRUCTIONS- NOTE: Some Motor Drive Junction Boxes and some Gyro Control Junction Boxes are upgraded with additional electromagnetic compatibility (EMC) components. Pictures and instructions for both types are provided.
  • Page 16 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 d. Upgraded units have an external ground stud. Use an M6 terminal lug to bond unit to vessel ground. 2) ORIGINAL GYRO CONTROL JUNCTION BOX POWER CONNECTION INSTRUCTIONS a. 24 VDC (nominal), 10 Amps.
  • Page 17 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 ELECTRICAL EQUIPMENT OTHER CONNECTION INSTRUCTIONS- 1) MOTOR DRIVE JUNCTION BOX CABLE CONNECTION INSTRUCTIONS a. Connect cables to the receptacles on the bottom of the Motor Drive Junction Box. CABLE 11...
  • Page 18 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 ELECTRICAL EQUIPMENT CABLE CONSTRUCTION- 1) CABLE 5 CONSTRUCTION a. Use field-wireable connector (provided) and 6x0.5mm cable (shipyard supply) to construct Cable 5 with the figure below. FIELD-WIREABLE TERMINAL VIEW FIELD-WIREABLE CONNECTOR...

  • Page 19: Section 3 - Cooling Installation

    DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Section 3 – Cooling Installation P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: customerservice@seakeeper.com...
  • Page 20 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Introduction – This section describes connection of glycol cooling hoses to drive enclosure, filling and purging of glycol circuit and connection of seawater to heat exchanger. Reference Drawings – 90001, Model 7000 Gyro Hardware Scope Of Supply 90003, Model 7000 Gyro Cooling Schematic 90004, Model 7000 Gyro Assembly &...
  • Page 21 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 • Glycol cooling pump must not be powered until glycol circuit is full. • Disconnect cable 17 on controller until ready to run pump. • 24 VDC must be available to controller before glycol circuit can be filled.
  • Page 22 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 For operation in areas without risk of freezing, mix 25% glycol with 75% distilled water in fill reservoir. For colder climates, a higher percentage of glycol up to a maximum of 50% should be used to provide adequate freeze protection.
  • Page 23 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Elevate reservoir above gyro. Open glycol spigot on reservoir. OPEN Connect glycol pump cable (17) to controller. Switch on controller breaker but do not run pump more than 5 seconds if glycol flow has not started.
  • Page 24 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Turn recirculation valve CCW to open then CW to close again. This can cause a pressure change and discharge of bubbles into return hose to reservoir. Repeat until bubbles are no longer seen.
  • Page 25 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 In this order, open glycol recirculation valve (A), close supply valve (B), close return valve (C). Thermal Valve should always be in full CW position: Listen to glycol pump after gyro has reached operating temperature (minimum 1 hour at speed). If intermittent cavitation is heard, air may again need to be purged by allowing glycol to recirculate to reservoir during precession.
  • Page 26 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 CONNECTING SEAWATER TO HEAT EXCHANGER - Connect seawater from installer supplied pump to ½” (12.5 mm) hose barb on gyro side of heat exchanger. Use the same practices as other below waterline seawater plumbing.
  • Page 27 DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Table 1: GLYCOL MIXTURE FREEZING POINTS Freezing Point Ethylene Glycol Solution (% by volume) Temperature Page 9 of 9...

  • Page 28: Section 4 - Startup

    DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Section 4 – Startup P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: customerservice@seakeeper.com...
  • Page 29 DOCUMENT # 90020, REV5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 Introduction – This section describes startup of gyro prior to sea trial. Also reference Seakeeper Document # 90021, Model 7000 Gyro Operators manual. STARTUP INSTRUCTIONS- 1) Forward aluminum crossbeam should be removed from Gyro foundation.
  • Page 30 DOCUMENT # 90020, REV5 MODEL 7000 GYRO INSTALLATION MANUAL-MAR09 7) Supply 220 VAC to drive and switch toggle handle breaker on drive on. A delayed click should be heard from internal contactor. CABLE 11 CABLE 14 CABLE 10 POWER CABLE 2 8) Click Run on keypad.

  • Page 31: Section 5 - Installation Checklist

    DOCUMENT # 90020, REV 5 MODEL 7000 GYRO INSTALLATION MANUAL MAR09 Section 5 – Installation Checklist P.O. BOX 999 14528 SOUTH SOLOMONS ISLAND ROAD. SOLOMONS, MARYLAND, 20688, U.S.A PHONE: 410-326-1590 FAX: 410-326-1199 E-MAIL: customerservice@seakeeper.com...
  • Page 32 Gyro Foundation Installed in Hull  Gyro Bonded to Foundation  Forward Cross Beam Removed After Bonding Electrical Checklist (reference Seakeeper Drawing 90005 & Installation Manual Section 2)  Mount Components Motor Drive Junction Box (near Gyro) Gyro Control Junction Box (near Gyro)
