Seakeeper 7000A GYRO Installation Manual

Hide thumbs Also See for 7000A GYRO:
Table of Contents

Advertisement

Quick Links

Download this manual
Product:
INSTALLATION
MANUAL
MODEL 7000A GYRO
MODEL 7000A GYRO
INSTALLATION MANUAL
JAN 2011
Contents:
Section 1 – Mechanical Installation
Section 2 – Electrical Installation
Section 3 – Cooling Installation
Section 4 – Startup
Section 5 – Installation Checklist and Required Supplies
P.O. BOX 809
44731 ST. ANDREWS CHURCH ROAD
CALIFORNIA, MARYLAND, 20619, U.S.A
PHONE: 410-326-1590
FAX: 410-326-1199
E-MAIL: customerservice@seakeeper.com
Document #:
Rev:
90051
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7000A GYRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seakeeper 7000A GYRO

Summary of Contents for Seakeeper 7000A GYRO

  • Page 1 Product: Document #: Rev: INSTALLATION MANUAL MODEL 7000A GYRO 90051 MODEL 7000A GYRO INSTALLATION MANUAL JAN 2011 Contents: Section 1 – Mechanical Installation Section 2 – Electrical Installation Section 3 – Cooling Installation Section 4 – Startup Section 5 – Installation Checklist and Required Supplies P.O.
  • Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 3: Section 1: Mechanical Installation

    This document is intended to give details and guidance to a boat builder or equipment installer to install the Seakeeper, Inc. Model 7000A Stabilizing Gyro. The gyro is capable of producing loads up to 23.5 kN (5300 lbs.) on each foundation saddle and careful consideration should be given to foundation design to insure it is capable of transferring these loads into the hull.
  • Page 4 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 2 of 10 Section 1: MECHANICAL INSTALLATION Precautions • Gyro flywheel is supported by precision bearings. Make certain while unpacking and lifting gyro assembly to NOT drop or impart mechanical shock as damage to bearings could result.
  • Page 5 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 3 of 10 Section 1: MECHANICAL INSTALLATION FIGURE 2A – INSTALLED GYRO CLEARANCE CONSIDERATIONS...
  • Page 6 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 4 of 10 Section 1: MECHANICAL INSTALLATION Refer to Figure 2B for recommended clearances to transverse beams. If a transverse beam is located under the forward brace, it must be 3” (76 mm) from the edge of the saddle beams to provide the necessary clearance for the swing of the motor power cable during gyro precession.
  • Page 7 ). The starboard saddle bond area is 310 (2002 cm Seakeeper has an optional installation jig available, P/N 90012, that is intended to duplicate the gyro foundation geometry in order to check clearances and alignment. The jig will allow the builder / installer to lay-up and adjust the foundation dimensions to create a low-clearance fit between the gyro foundation saddles and the hull structure.
  • Page 8 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 6 of 10 Section 1: MECHANICAL INSTALLATION FIGURE 3 – INSTALLATION JIG...
  • Page 9 Noise/Soundproofing/Ventilation Gyro noise has been measured under steady state conditions (no wave load) in Seakeeper's lab and in our 43 ft Viking test boat. The steady state noise is typically in the range of 70-75 dB unweighted. As the...

  • Page 10: Unpacking Crate

    8 of 10 Section 1: MECHANICAL INSTALLATION Unpacking Crate 1) Reference Seakeeper Drawing No. 90030, Model 7000A Hardware Scope of Supply for items that ship with the gyro. 2) Remove electrical components, cables, and misc. items and set aside. 3) Remove “tray” and packing materials that secure gyro assembly inside the crate.
  • Page 11 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 9 of 10 Section 1: MECHANICAL INSTALLATION Installation of Gyro 1) Position Gyro near foundation. 2) Perform dry fit of gyro assembly over hull structure (no adhesive) to confirm that fit is good.
  • Page 12 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 10 of 10 Section 1: MECHANICAL INSTALLATION 8) Thoroughly clean hull structure with appropriate solvent where the saddles will be bonded. 9) Apply adhesive to both the saddles and the hull structure in a manner that all gaps between the saddles and the hull structure will be filled with adhesive when the gyro is lowered into position.
  • Page 13 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  1 of 16    Section 2:  ELECTRICAL INSTALLATION    Introduction  This  section  for  electrical  installation  explains  how  to  mount  the  electrical  equipment  and  how  to  connect the electrical cables.  Reference Drawings  Reference Work Instructions  90030  Model 7000A Gyro Hardware Scope of Supply  020  Installation Instructions,  90023  Model 7000A Gyro Cable Block Diagram    24VDC Power Connector  90007 ...
  • Page 14 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  2 of 16    Section 2:  ELECTRICAL INSTALLATION    Electrical Equipment Mounting  Precautions   Each item of electrical equipment has specific mounting instructions.  These instructions should  be followed to insure proper function of the Model 7000A Gyro.    Do NOT move gyro Control Box from its location or incorrect gyro operation  will result.        1. MOTOR DRIVE JUNCTION BOX MOUNTING INSTRUCTIONS  a. Bulkhead space required:  Approx. 19 W x 31 H inches (483 x 787 mm);  b. Hardware required:  Four mounting screws through two mounting brackets to primary  vessel structure at four corners.  Mounting hole diameter .219” (5.5 mm), See drawing  90007 for hole locations.  Location:  In dry space, optimal for cables and tubing, within 8.2 ft (2.5 m)  from Gyro.  c. Orientation:  Not critical.      2. PCB GYRO CONTROL JUNCTION BOX MOUNTING INSTRUCTIONS  a.
  • Page 15 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  3 of 16    Section 2:  ELECTRICAL INSTALLATION    4. KEYPAD MOUNTING INSTRUCTIONS  a. Console space required:  Approx. 3.5 W x 4 H inches (89 x 102 mm)  b. Mounting Instructions:  Front mount to vessel console panel; 1.25" x 2.13" (31.8 mm x  54.0 mm) oval hole for wire harness; two 10‐32 screw holes; mount with 10‐32 locknuts,  provided.  See drawing 90035 for hole locations.  c. Hardware Required: none.  d. Maximum panel thickness:  .4 inches (10 mm)  e. Minimum panel thickness:  .04 inches (1 mm)      5. DISPLAY MOUNTING INSTRUCTIONS  a. Console space required:  Approx. 3 W x 3 H inches (76 x 76 mm)  b. Mounting Instructions:  Front mount to vessel console panel, 2.125 inch (54 mm) hole;  with threaded mounting collar.  See drawing 90009 for details.  c. Hardware required: none.  d. Maximum panel thickness:  1.38 inches (35 mm)  e.
  • Page 16   Electrical Equipment Power Connections  1. 230 VAC POWER SOURCE REQUIREMENTS  a. 230 VAC (nominal), 1 Phase, 50/60 Hz, 20 Amps.  b. A separate circuit breaker should be used for each Motor Drive J‐Box.    2. 24 VDC POWER SOURCE REQUIREMENTS  a. 24 VDC, 10 Amps.  b. A separate breaker should be used for each Gyro Control Box.  The vessel breaker should be labeled “Do Not Turn Off Except for Service”.     3. 24V DELAY‐OFF TIMER BOX  a. The 24V Delay‐Off Timer Box (Seakeeper Part No. 20115) must be installed between the  vessel breakers and the gyro system as shown in Figure 2.    3x10 AWG CA BLE 2 CUSTOME R MOTOR DRIVE GYRO AC 3x1 0AWG CUSTOMER SUPPLIED CUSTOMER DISCONNECT S UPP LIED...

  • Page 17: Safety Ground

      FIGURE 4 – MOTOR DRIVE J‐BOX SAFETY GROUND CONNECTION  iii. Tighten cable gland nut to compress strain relief onto cable.  If cable is not tight,  apply silicone to seal penetration into enclosure to protect internal components from  corrosion.   See Figure 5.    b. Electromagnetic  compatibility  grounding  by  the  external  ground  stud.    Connect  Cable  9,  4AWG  Ground  Cable  (Seakeeper  P/N:  20094),  to  Motor  Drive  JB  from  Gyro  rear  brace  (factory installed at rear brace).  CABLE    GLAND NUT    ...
  • Page 18 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  6 of 16    Section 2:  ELECTRICAL INSTALLATION      5. GYRO CONTROL BOX POWER CONNECTION INSTRUCTIONS  a. 24 VDC, 10 Amps.  2 x 12AWG (3 x 4mm  CSA) customer supplied.  i. Install Seakeeper provided connector P/N: 30104 (Turck P/N: B4131‐0/13,5) on CABLE  1 using Work Instruction 020.              FIGURE 7 – SEAKEEPER PROVIDED 24VDC POWER INPUT CONNECTOR    ii. Connect CABLE 1 to J10 on PCB Gyro Control Box.          J10    24 VDC  Input  ...
  • Page 19 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  7 of 16    Section 2:  ELECTRICAL INSTALLATION       Electrical Equipment Signal Connections    1. MOTOR DRIVE JUNCTION BOX CABLE  a. Connect  cables  to  the  receptacles  on  the  bottom  of  the  Motor  Drive  Junction  Box.   These connectors come from the factory completely installed on the cables.  i. J1:  Motor Power, CABLE 10 from Gyro sphere.  ii. J2:  Drive Control, CABLE 14 from PCB Gyro Control Box.  iii. J3:  Motor Instrumentation, CABLE 11 from Gyro sphere.   ...
  • Page 20 Breakout Box.  1. Install Seakeeper provided connector P/N: 30076 (Turck  P/N: 8181‐0) on CABLE 5 using Work Instruction 018.  ix. J9:  Switched Outputs, CABLE 8 (4x22AWG w/ shield, max OD  =  8mm,  Customer  supplied)  to  Alarm  &  Monitoring  System  and Seawater Pump Control Relay.  FIGURE 10 – PCB GYRO CONTROL  JUNCTION BOX CONNECTORS  1. Install  Seakeeper  provided  connector  P/N:  30078  (TurckP/N:  8141‐0)  on  CABLE  8  using  Work  Instruction              019. ...
  • Page 21 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  9 of 16    Section 2:  ELECTRICAL INSTALLATION      3. ALARM OUTPUT CONNECTION INSTRUCTIONS    Do not connect J9 to voltage over 30VDC or damage may result.  Do not connect J9 to AC voltage  or damage may result.  a. The Alarm output is one of 2 switched output signals at receptacle J9.  This connector is  shared with the Seawater Pump Control output.  b. The Alarm output is volts‐free or dry contacts, meaning a control voltage must be  connected to activate whatever alarm circuit is used.  c. The Alarm output should go to the boat’s Alarm & Monitoring System or a suitable  audible and visual alarm.  Suggested wiring is shown in Figure 11.  d. The Alarm output logic is:  open contacts = Alarm or power is off      4. SEAWATER PUMP CONTROL CONNECTION INSTRUCTIONS  The seawater pump power must be on a separate circuit breaker from the Gyro Control Box  24VDC breaker and the Motor Drive J‐Box 230VAC breaker.  Do not connect J9 to voltage  over 30VDC or damage may result.  Do not connect J9 to AC voltage, or damage may result.  a. The Seawater Pump Control output is the other of 2 switched output signals at  receptacle J9.  This connector is shared with the Alarm output.  b.
  • Page 22 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  10 of 16    Section 2:  ELECTRICAL INSTALLATION                                                      FIGURE 11 – ALARM OUTPUT AND SEAWATER PUMP CONTROL CONNECTIONS ...
  • Page 23 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  11 of 16    Section 2:  ELECTRICAL INSTALLATION    5.  GYRO TO VESSEL GROUND CONNECTION INSTRUCTIONS  a. The Gyro foundation is connected to vessel ground.  i. Install  CABLE  15  (4AWG,  Customer  supplied)  from  one  of  the  available  brass  ground studs on the Gyro rear brace to a suitable vessel ground.  ii.   iii.   iv.   v.   vi.   b.

  • Page 24: Operator Station

    Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  12 of 16    Section 2:  ELECTRICAL INSTALLATION      Operator Station    This  section  explains  the  connection  between  the  Operator  Station  equipment  and  the  Gyro  Control  Box.  Reference Drawing  90023  Model 7000A Gyro Cable Block Diagram    1. DETERMINE LOCATION OF OPERATOR STATION  a. The  desired  location  of  the  Operator  Station  must  be  determined  with  respect  to  the  vessel arrangement. ...
  • Page 25 90051  3  13 of 16    Section 2:  ELECTRICAL INSTALLATION      2. ROUTE SERIAL COMMUNICATIONS CABLE  a. Customer supplied CABLE 5: 6x20AWG shielded cable with a maximum outer diameter  of 8mm (0.315 inch).  b. CABLE 5 must be routed and installed in the vessel between the PCB Gyro Control Box  and the Operator Station.  3. INSTALL OPERATOR STATION EQUIPMENT  a. The Operator Station equipment is installed at the determined location using Electrical  Equipment Mounting Instructions in Section 2.1 steps 1 ‐ 6.  4. CONNECT OPERATOR STATION EQUIPMENT  a. The  Operator  Station  equipment  is  connected  in  accordance  with  the  Cable  Block  Diagram, 90023.  b. Install Seakeeper provided connector P/N: 30076 (Turck P/N: 8181‐0) on CABLE 5 using  Work Instruction 018.   ...
  • Page 26 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  14 of 16    Section 2:  ELECTRICAL INSTALLATION    Second Operator Station Connection  This section explains how to connect the 2  Operator Station Kit.    Reference Drawings  90040  Model 7000A Gyro 2  Operator Station Kit  90034  Model 7000A Gyro with 2 Operator Stations Cable Block Diagram    1. DETERMINE LOCATION OF 2  OPERATOR STATION  a. The desired location of the 2  Operator Station must be determined with respect to the   Operator Station and the vessel arrangement.  b. Typical locations include:  i. Flybridge  ii. Engine room  2. DETERMINE CABLING ARRANGEMENT  a. The  figure  below  shows  the  entire  serial  communications  link  for  2  Operator  Stations.   The ...
  • Page 27 Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  15 of 16    Section 2:  ELECTRICAL INSTALLATION    3. ROUTE 2  OPERATOR STATION CABLE  a. Customer supplied CABLE 19 is the same cable material as CABLE 5: 6x20AWG shielded  cable with a maximum outer diameter of 8mm (0.315 inch).  b. CABLE 19 must be routed and installed in the vessel between the 1  and 2  Operator  Stations.  4. INSTALL 2  OPERATOR STATION EQUIPMENT  a. The  2   Operator  Station  equipment  is  installed  at  the  determined  location  using  Electrical Equipment Mounting Instructions in Section 2.1 steps 3 ‐ 6. ...

  • Page 28: Work Instructions

    Product:  Document #:  Rev:  Page:  INSTALLATION  MANUAL  MODEL 7000A GYRO  90051  3  16 of 16    Section 2:  ELECTRICAL INSTALLATION       Work Instructions       Work Instruction 018  Installation Instructions, 8‐Pin Shielded EMC Connector   Work Instruction 019  Installation Instructions, 4‐Pin Shielded EMC Connector   Work Instruction 020  Installation Instructions, 24 VDC Power Connector ...
  • Page 29 WORK Product: M7000A Document #: 018 INSTRUCTIONS Process: Installation Instructions, 8-Pin Shielded EMC Connector Rev.: 2 Process Description: Component identification, cable preparation, and Page 1 of 4 connector installation for 8-pin all-metal, shielded connector. 8-Pin Shielded Serial Communications Connector for Gyro Control J-Box, Turck 8181-0 Connector Shielding Bell...
  • Page 30 WORK INSTRUCTIONS Page 2 of 4 Product: M7000A Document #: 018 Process: Installation Instructions, 8-Pin Shielded EMC Connector Rev.: 2 Step 3 - 7 Trim cable jacket as shown in cable preparation detail. Fold braided shield back over cable to expose inner conductors.
  • Page 31 WORK INSTRUCTIONS Page 3 of 4 Product: M7000A Document #: 018 Process: Installation Instructions, 8-Pin Shielded EMC Connector Rev.: 2 Steps 8 – 12 Position backshell, with shielding bell inside, over screw clamps and thread into connector Flare shield then insert seal behind shield (cutaway view of backshell on connector).
  • Page 32 WORK INSTRUCTIONS Page 4 of 4 Product: M7000A Document #: 018 Process: Installation Instructions, 8-Pin Shielded EMC Connector Rev.: 2 Serial Communications Cable Connections Note: Conductors “E” and “F” are reversed at Network Breakout Box Rear View of 8-Pin Shielded Connector Inside View of Network Breakout Box Terminals Note swapped wires above for terminals 5 &...
  • Page 33 WORK Product: M7000A Document #: 019 INSTRUCTIONS Process: Installation Instructions, 4-Pin Shielded EMC Connector Rev.: 2 Process Description: Component identification, cable preparation, and Page 1 of 4 connector installation for 4-pin all-metal, shielded connector. 4-Pin Shielded Switched Output Connector for PCB Gyro Control J-Box, Turck 8141-0 Connector Shielding Bell...
  • Page 34 WORK INSTRUCTIONS Page 2 of 4 Product: M7000A Document #: 019 Process: Installation Instructions, 4-Pin Shielded EMC Connector Rev.: 2 Step 3 - 7 Trim cable jacket as shown in cable preparation detail. Fold braided shield back over cable to expose inner conductors.
  • Page 35 WORK INSTRUCTIONS Page 3 of 4 Product: M7000A Document #: 019 Process: Installation Instructions, 4-Pin Shielded EMC Connector Rev.: 2 Steps 8 – 12 Position backshell, with shielding bell inside, over screw clamps and thread into connector Flare shield then insert seal behind shield (cutaway view of backshell on connector).
  • Page 36 Page 4 of 4 Product: M7000A Document #: 019 Process: Installation Instructions, 4-Pin Shielded EMC Connector Rev.: 2 Wiring Diagram for Switched Outputs CONNECTOR, M7000A GYRO SEAKEEPER CONTROL J-BOX PROVIDED CUSTOMER SUPPLIED J-BOX CABLE 8 RESETTABLE CUSTOMER FUSE, 24V, SUPPLIED 0.77A @ 60C...
  • Page 37 WORK Product: M7000A Document #: 020 INSTRUCTIONS Process: Installation Instructions, 24VDC Power Connector for PCB Gyro Rev.: 1 Control J-Box Process Description: Component identification, cable preparation, and Page 1 of 3 connector installation for field-wireable power connector. 24VDC Power Cable Connector for PCB Gyro Control J-Box Turck B 4131-0/13,5 Connector Backshell...
  • Page 38 WORK INSTRUCTIONS Product: M7000A Document #: 020 Page 2 of 3 Process: Installation Instructions, 24VDC Power Connector for PCB Gyro Rev.: 1 Control J-Box Steps 3 - 8 3. Trim cable jacket as shown. 4. Strip insulation on wires as shown. 5.
  • Page 39 WORK INSTRUCTIONS Product: M7000A Document #: 020 Page 3 of 3 Process: Installation Instructions, 24VDC Power Connector for PCB Gyro Rev.: 1 Control J-Box Step 9 If label is used: Print adhesive-backed labels with appropriate text. Install on cable jacket approximately as shown below, then cover with clear, heat-shrinkable tubing.
  • Page 40 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 41 This section describes connection of glycol cooling hoses to drive enclosure, filling and purging of glycol circuit, and connection of seawater to heat exchanger. Reference Drawings 90030 Model 7000A Gyro Hardware Scope of Supply 90003 Model 7000 Gyro Cooling Schematic 90032 Model 7000A Gyro Assembly & Parts List 90023 Model 7000A Gyro Cable Block Diagram FIGURE 1 –...
  • Page 42 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 2 of 9 Section 3: COOLING INSTALLATION FIGURE 2 – MODEL 7000A GYRO (hydraulic hoses removed for clarity) FIGURE 3 – J2 CABLE at J2 CONNECTOR FIGURE 4 – PUMP CONNECTOR...
  • Page 43 3) Slotted screwdriver 4) Razor knife or tube cutter 5) Glycol fill reservoir and 3/8 inch (9.5 mm) ID tube (Seakeeper Part No. 10353 - Glycol Fill Kit includes reservoir and tubing) Glycol Circuit Connections to Drive Enclosure 1) After mounting drive enclosure, route and secure hoses from gyro. Hoses may be cut to appropriate length.
  • Page 44 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 4 of 9 Section 3: COOLING INSTALLATION 3) Use hose clamps to secure hoses. TO GYRO FROM HYD MANIFOLD Procedure for Filling and Purging Glycol Circuit Start with connector J2 on the Gyro Control Box disconnected to prevent running the glycol pump without fluid.
  • Page 45 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 5 of 9 Section 3: COOLING INSTALLATION Set service valves open and recirculate valve closed as shown below.
  • Page 46 6 of 9 Section 3: COOLING INSTALLATION Elevate reservoir ABOVE the top of the gyro OR the Motor Drive J-Box, whichever is higher. Open glycol spigot on reservoir. For Seakeeper reservoir, open position is with valve at 90° as OPEN shown below.
  • Page 47 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 7 of 9 Section 3: COOLING INSTALLATION On Display, repeatedly press MENU button to scroll to the Service screen. Press DOWN button three times to select Brake. Then press MENU button to go to the Brake Screen.
  • Page 48 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 8 of 9 Section 3: COOLING INSTALLATION Manually precess gyro back and forth through full stroke as shown while glycol is recirculating to reservoir. Bubbles should appear in return hose. Continue until bubbles are no longer observed and finish with an additional three full stroke precession cycles.
  • Page 49 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 9 of 9 Section 3: COOLING INSTALLATION Thermal Valve should always be in full CW position. The reservoir may now be disconnected from the cooling circuit by removing the hoses at the glycol service ports.
  • Page 50 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 51: Section 4: Startup

    This section describes the first startup of the gyro. Gyro will be run at 1000 rpm and 9700 rpm to check system operation. Also reference Seakeeper Document # 90052, Model 7000A Gyro Operation Manual. • Before continuing, the area around the gyro must be clear of personnel and equipment! •...
  • Page 52 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 2 of 3 Section 4: STARTUP 4) Turn on the boat’s AC or DC circuit breaker that supplies power to the sea water pump. 5) Repeatedly press the MENU button on the Display to scroll through screens. Check for correct indication of: Gyro Angle –...
  • Page 53 Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 3 of 3 Section 4: STARTUP 11) Repeatedly press the MENU button to return to the SPEED COMMAND screen. Press the UP button twice on display to change the speed to 9700 rpm. Gyro will continue to spool up until reaching 9700 rpm.
  • Page 54 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 55: Installation Checklist

    Installation Checklist Mechanical Checklist (reference Installation Manual Section 1) Gyro Foundation Installed in Hull  Electrical Checklist (reference Seakeeper Drawing 90023 & Installation Manual Section 2) Mount Components  1. Motor Drive Junction Box (near Gyro) 2. Display (near helm) 3.
  • Page 56 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 2 of 4 Section 5: INSTALLATION CHECKLIST AND SUPPLIES Cooling Checklist (reference Installation Manual Section 3) Mix 3 Liters ethylene glycol with 3 Liters distilled water in glycol reservoir ...

  • Page 57: Item Description

    Mechanical .8 gal (3L) glycol Cooling .8 gal (3L) distilled water Cooling Glycol Fill Kit (includes reservoir and tubing) Seakeeper Part No. 10353 Cooling Clamps for reservoir hoses 3/8" (9.5 mm) hose barb Cooling Hose clamps for seawater plumbing to 1/2" (12.5 mm) hose...
  • Page 58 Product: Document #: Rev: Page: INSTALLATION MANUAL MODEL 7000A GYRO 90051 4 of 4 Section 5: INSTALLATION CHECKLIST AND SUPPLIES List of common tools that may be required for installation Item Description Wire cutter Power, serial comm cables Wire stripper...
