SEAKEEPER CONNECTBOX USER'S MANUAL
PRODUCT CONNECTBOX
SEAKEEPER MFD OR DISPLAY APPLICATION
The ConnectBox requires a display interface. The Seakeeper may connect to a compatible MFD,
an optional Seakeeper 5" Touch Display, or both an MFD and a 5" display. At the MFD or 5"
display, the Seakeeper application acts as the interface for the user to remotely start and stop
the Seakeeper, view Seakeeper operating parameters, adjust settings, and acknowledge
Seakeeper notifications or alarms.
visual guide to navigating the multiple screens available in the application. Each Seakeeper's
operation manual (manuals.seakeeper.com) also describes the various screens.
HOME SCREEN
After the Seakeeper ConnectBox and Application have been initialized, the Application Home
screen will be displayed (Figure 14). Users have two home screen views from which to choose. To
toggle the two options, the user only needs to press the alternate view icon in the lower-left
corner of the screen (seen circled in Figure 14).
From the Home screen, the user can initiate the flywheel spool up or shut down by pressing the
power button . When the gray-shaded power button is pressed, the flywheel motor starts
and the button turns blue
flywheel motor is deenergized and the button turns back to gray.
Page 13 of 27
Document # 90769-1
TB-90653, Seakeeper Display
Figure 14: Two Home screen options shown
. When a running Seakeeper's power button is pressed, the
Navigation, provides a generic
