8.1.7 Stop state alarm
Table 68: Stop state alarm
Label Alarm Actions during ac‐
descrip‐ tive
tion
W002 Standby
mode
8.1.8 Manual mode alarm
Table 69: Manual mode alarm
Label Alarm description Actions during ac‐
tive
W003 Manual control
8.1.9 Index Alarm
Table 70: Alarm label
Label Alarm name
E100 Valve con guration error
E101 Con guration error
E102 Sensor supply overload
E024 S2 suction pipe sensor error
E025 S3 media inlet sensor error
E026 S4 media outlet sensor error
E020 Pe evaporator transmitter error
E121 Pc condenser transmitter error
E019 External reference signal alarm
E011 No refrigerant selected
E103 No valve con gured
E122 Shared signal timeout
E128 Ext. ref. signal timeout
A997 Battery critical low voltage
A996 Battery too high voltage
W001 Battery low voltage
A994 Low S4 media outlet temperature
A993 High temperature
A992 Low temperature
A991 High evaporation pressure (MOP)
A990 Low evaporation pressure (LOP)
A989 High condensing temperature
A988 High superheat
A987 Low superheat
A986 Lack of valve capacity
W002 Standby mode
W003 Manual control
SH reference too close to SH close
E104
setpoint
LOP setpoint too close to MOP set-
E105
point
E129 No sensor con gured for S4
E106 No sensor con gured for S3
E107 SH min higher than SH max
E108 OD min higher than OD max
E109 No transmitter con gured for Pc
Check valve step mode vs position-
E114
ing
E115 Valve speed too fast
E116 Valve speed too slow
© Danfoss | Climate Solutions | 2024.08
Trigger (how the alarm IS How to clear the alarm
raised)
Controller is in stop state Controller not in stop state
Trigger (how the alarm IS How to clear the alarm
raised)
Controller is in manual state Controller not in manual state
Modbus PNU Bit number
1901 8
1901 9
1901 10
1901 11
1901 12
1901 13
1901 14
1901 15
1901 0
1901 1
1901 2
1901 3
1901 4
1901 5
1901 6
1901 7
1902 8
1902 9
1902 10
1902 11
1902 12
1902 13
1902 14
1902 15
1902 0
1902 1
1902 2
1902 3
1902 4
1902 5
1902 6
1902 7
1903 8
1903 9
1903 10
1903 11
1903 12
Remark
The controller is standby due R012 Main
switch and/or DI main switch is o
Remark
The controller is manual control, no auto-
matic control is active, and many alarms
are disabled
Can Index Can Subindex
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6C
5507 6E
5507 6E
5507 6E
5507 6E
5507 6E
