Superheat controller and stepper valve driver, Type EKE 1A, 1B, 1C, 1D
8.1.5 Application alarms
Table 66: Application alarms
Label Alarm description Actions during ac‐
tive
A994 Low S4 media outlet
temperature
A991 High evaporation
pressure (MOP)
A990 Low evaporation
pressure (LOP)
A989 High condensing
temperature
A988 (1) High superheat
A987 (2) Low superheat
A986 Lack of valve capaci-
ty
E135 Error in Heat/Cold in
thermostat mode
(1) (1)
• Length of monitoring window for High superheat detection can be adjusted using parameter [A108 – High SH alarm delay]. If the parameter • Length of monitoring window for High superheat detection can be adjusted using parameter [A108 – High SH alarm delay]. If the parameter
is set to 0 the function is disabled. is set to 0 the function is disabled.
• The high superheat limit is de ned by the user through parameter [A109 – High SH alarm di erential] High superheat limit= SH ref+ High SH • The high superheat limit is de ned by the user through parameter [A109 – High SH alarm di erential] High superheat limit= SH ref+ High SH
alarm di erential. alarm di erential.
(2) (2)
• Length of monitoring window for Low superheat detection can be adjusted using parameter [A110 – Low SH alarm delay]. If the parameter • Length of monitoring window for Low superheat detection can be adjusted using parameter [A110 – Low SH alarm delay]. If the parameter
is set to 0 the function is disabled. is set to 0 the function is disabled.
• The high superheat limit is de ned by the user through parameter [A998 - Low SH alarm di erential] • The high superheat limit is de ned by the user through parameter [A998 - Low SH alarm di erential]
Low superheat limit= SH ref- Low SH alarm di erential, If Low superheat limit is lower than SH close set point, then Low superheat limit= SH ref- Low SH alarm di erential, If Low superheat limit is lower than SH close set point, then
Low superheat limit= SH close set point. Low superheat limit= SH close set point.
8.1.6 Thermostat alarms
Table 67: Thermostat alarms
Label Alarm description Actions during ac‐
tive
A993 High temperature
A992 Low temperature
