3 Components and Power Supply
3.7.5 Connecting for configuration
The M10-Smart router has an RJ45 female connector on the rear panel (labeled "CONSOLE.") that provides access
to the device's local console
For further information, please see
CONSOLE. Connector
Fig. 16:
3.8 Installing the SIM card
The M10-Smart router has a Wireless WAN interface that may need a SIM card to operate.
The M10-Smart has one protected SIM tray located on its side panel, as shown in the following figure.
Fig. 17: SIM tray
To access the internal SIM, remove the SIM cover and insert the SIM card in its slot.
(1) Use a Phillips PH1 screwdriver to loosen the screw of the card slot cover found on the side of the router and re-
move the cover.
(2) Press to insert the SIM card into the selected tray or remove it from there.
(3) Insert the card slot cover and tighten the screw.
Warning
Never install the SIM cards when the device is switched on.
Always disconnect the device form the main power supply before installing the SIM cards.
Always disconnect the device before removing the casing to access the trays.
When inserting the SIM cards, please protect yourself against electrostatic discharges (ESD).
Do not touch the SIM card connectors.
16
Connecting to the device on page 23.
