Technical Information
A.4.5 USB 3.0 connector
Type-A
A.4.6 Configuration connector
RJ45 CONFIGURATION
A.4.7 Power supply connector
Jack 5.5/2.5mm
26
Internal
External
PIN
1
2
3
4
5
6
7
8
Shell
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal -> POSITIVE
External -> NEGATIVE
RF in/out
GND
Signal
VBUS
D- (USB 2.0)
D+ (USB 2.0)
SSRX- (USB 3.0)
SSRX+ (USB3.0)
GND_DRAIN
SSTX- (USB 3.0)
SSTX+ (USB 3.0)
Shield
CONF
--
--
TxD
GND
GND
RxD
--
--
Teldat S.A.
M10-Smart
