3 Components and Power Supply
3.3.2 Wall mounting
The M10-Smart can be mounted on the wall.
There are two slots on the underside of the device, used to fix it to the wall.
We recommend the following accessories for wall mounting, valid for solid and Gypsum board (plaster) walls:
• 2 screws: M4x20, 6.50-7mm diameter, 2.0mm head, 20mm length.
Screw
Fig. 8:
• 2 wall anchors: 1/4X1, 8 mm diameter, 25mm length.
Wall anchor
Fig. 9:
Warning
The screws must go into a wall stud (wood) or a wall anchor of the appropriate type for the wall. Screws
into drywall are not strong enough to mount the router.
Warning
Make sure that there are no concealed pipes and cables at the desired drilling location before drilling
any mounting holes. Damage to electricity cables, gas, water and sewage pipes can result in death or
material damage. Choose the installation location so that as few obstacles or electrical appliances as
possible disturb the connection.
Note
The screws and anchors are not delivered with the router.
There are two slots on the underside of the device that can be used to fix it to the wall. You can see this in the follow-
ing figure:
