3 Components and Power Supply
Note
These WAN interfaces have a UTP/Fiber Media Auto Detection feature.
Only one of the connectors must be used for proper operability.
Note
WAN connectors do not work during booting and in BIOS mode.
Note
An appropriate software license may be required for the second WAN (WAN 2) interface to work.
3.7.2.1 Laser information
Warning
Laser Radiation. Do not use optical instruments directly or without proper protection. CLASS 1 LASER
PRODUCT.
The SFP modules to be installed in the card socket should be class 1 devices that comply with the IEC/
EN 60825-1:2007 standard.
3.7.3 WWAN antenna connection (cell connector)
The M10-Smart has two connectors for WWAN antennas on the rear panel for installing the provided antennas.
To assemble or dismantle the antennas, simply screw or unscrew them into or out of the SMA connectors located on
the rear panel of the router.
Installing these antennas in the M10-Smart is essential to improve the quality of the signal received and transmitted
by the cellular model.
Note
To achieve high-quality performance, the router should always have the WWAN antennas installed.
Some cellular telephony technologies use the antenna diversity technique to improve the quality of the received sig-
nal . The M10-Smart router family incorporates several WWAN connectors for this.
14
Choose SFP transceivers that meet the following regulations
• Class 1
• IEC/EN60825-1:2007 2nd Edition or a later one, European standard
• FCC 21 CFR Chapter 1, Subchapter J (in accordance with FDA and CDRH re-
quirements)
• Application of CE marking in accordance with the 2014/30/EU EMC Directive
and the 2014/35/EU Low Voltage Directive
• UL and/or CSA registered component for North America
• 47 CFR Part 15, Class A
Teldat S.A.
M10-Smart
