Chapter 2: Jumpers and Connectors
Locations of the Jumpers and Connectors
The following figure shows the motherboard of DNA141 and indicates the locations of jumpers and connectors. Refer to this chapter for detailed pin setting
and definitions of connectors marked in pink on this figure.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
LED1
LED4
LED5
LED15
LED3
DIMM1
COM1
CN4
SW2
CN5
LED6
CN2
CN1
LAN1
SW1
7
JP2
JP3
JP4
BAT1
DNA 141 User Manual
