Right View - Model A Design II
1
On this computer model there is one USB 3.2 Gen 1 Type A port, One USB 3.2 Gen 2 Type
A port, one USB 3.2 Gen 2 Type C port with Power Delivery DC-In Function and one Dis-
playPort 1.4, Over USB 3.2 Gen 2 Type C port.
Note: The maximum amount of current supplied by the USB ports is 900 mA for USB 3.2 &
Type C.
he USB 3.2 Gen 2 Type C port with Power Delivery DC-In Function allows you to use a
T
power source, with a USB Type C cable and connector, plugged into the port to charge the
computer.
Make sure any power source is appropriately certified, and complies with the USB-C PD
(Power Delivery) standard specification rated at 20Vdc, 5A, or 20 Vdc 3.25A (for off mode
charge).
3
2

USB Ports
Power Delivery with DC-In USB Port
4
Right View - Model A Design II 1 - 25
Quick Start Guide
Figure 1 - 17
Right View
1. Speaker
2. USB 3.2 Gen 2
Port (Type A)
3. USB 3.2 Gen 2
Port (Type C) with
Power Delivery
DC-In Function
4. Vent/Fan Intake

Overheating
To prevent your comput-
er from overheating make
sure nothing blocks the
Vent/Fan Intake while the
computer is in use.
