EUROCOM Nightsky RX415z User Manual page 50

Quick Start Guide
1
Figure 1 - 10
Front & Left Views
1. LED Indicators
2. Security Lock
Slot
3. Vent/Fan Intake/
Outlet
4. USB 3.2 Gen 1
Type A Port
5. 2-In-1 Audio Jack
(Headphone/
Microphone)
6. Speaker

Overheating
To prevent your computer
from overheating make sure
nothing blocks the Vent/Fan
Intake while the computer is
in use.
1 - 18 Front & Left Views - Model B
Front & Left Views - Model B
3
2
Note that 2-In-1 combination audio jacks can support headphones, headsets (i.e. a combi-
nation microphone/headphone), microphones and speakers.
1. When a device is plugged in to the combination audio jack a a dialog ("Which device
did you plug in?") box will pop-up
2. Make sure you select the correct device from the drop-down menu corresponding to
the device plugged-in (e.g. choose "Headset" if you have plugged-in a headset
and do not choose headphone in this case), and then click OK to save the setting.
4 5

2-In-1 Combination Audio Jacks
1
6
