EUROCOM Nightsky RX415z User Manual page 168

Modules & Options
Figure 6 - 4
Select Disks
6
6 - 8 RAID Mode Setup
14. Go to any of the disks listed under "Select Disks:" and select a disk name.
15. Click on X to select the disk required.
16. You should select two or three identical SSDs (three SSDs are required for RAID
5) to form your RAID volume.
17. If you have selected RAID0 (Stripe) then you can adjust the "Strip Size" to (you
can use the cursor to move up and down the menu selection) your requirements (it
is recommended that you set the "Strip Size" to 128KB).
18. Select Create Volume (make sure you have selected your disks).
19. The system will list your RAID volume.
