  • Page 3 Preface Notebook Computer R130T Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the R130T series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD ....................A-5 DVD Super Multi ................A-6 Overview ..................1-1 Schematic Diagrams......... B-1 System Specifications ..............1-2 External Locator - Top View with LCD Panel Open ......1-4 System Block Diagram ..............B-2 External Locator - Front & Right side Views .........1-5 HDI Con ..................B-3 External Locator - Left Side &...
  • Page 12 Preface...

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the R130T series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g.

  • Page 14: System Specifications

    Introduction System Specifications Video Interface Processor Intel® GS45 Integrated Video Three USB 2.0 Ports Intel® Core™2 Duo Processor ULV: High Preference 3D/2D Graphic Accelerator One Serial (COM1) Port SU9300 (1.20GHz) Shared Memory Architecture of up to 256M One External Monitor Port 45nm (45 Nanometer) Process Technology, Supports Microsoft DirectX 10 One Headphone-Out Jack...
  • Page 15 Introduction Communication Security Optional Built-In 10M/100M/100M Base-TX Ethernet LAN Security (Kensington® Type) Lock Slot Super Multi Optical Device Drive Bluetooth 2.1 + EDR (Enhanced Data Rate) Fingerprint ID Reader Module Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/ Module (Factory Option) BIOS Password n) Wireless LAN PCIe interface Half Mini-Card Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. LCD Latch 2. Built-In PC Camera (Optional) 3. LCD 4. Power Button 5. Keyboard 6. Fingerprint Reader Module 7. Touchpad & Buttons 8. Built-In Microphone 9.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LCD Latch 2. Carrying Handle 3. Speakers Figure 3 Right Side Views 4. Optical Device Drive Bay (for CD/DVD Device) 5. ODD Lock 6. 1 * USB 2.0 Port 7.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View DC-In Jack External Monitor Port S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Vent/Fan Intake/ Outlet RJ-45 LAN Jack 2 * USB 2.0 Port ExpressCard Slot 10. 7-in-1 Card Reader Figure 5 Rear View 11.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Hard Disk Bay Cover 3. RAM & CPU Bay Cover 4. Vent/Fan Intake/ Outlet 5. Drainage Outlet  Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in-...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. ExpressCard Connector 2. KBC ITE IT8513E 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (3G Module) 2. SIM Card Socket 3. Mini-Card Connector (WLAN Module) 4. CPU and Memory Card Slot 5. Card Reader Socket Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. LED Connector 2. CCD Connector 3. Comport Connector 4. Power Button Connector 5. SATA HDD Connector 6. Keyboard Cable Connector 7. ODD Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CPU Fan Cable Connector 2. Bluetooth Module Connector 3. GPS Module Connector 4. Touchpad Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the R130T series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. a. Slide the latch in the di- 1. Turn the computer off, and turn it over. rection of the arrow.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" SATA hard disk HDD Assembly drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary driv- Removal ers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.

  • Page 31: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 3 Optical Device 1. Turn off the computer, and turn it over and remove the battery (page 2 - Removal 2. Locate the RAM & CPU bay cover and remove screws 3. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover a.

  • Page 32: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) DDR II Removal (DDR2) supporting 800 MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR Modules.
  • Page 33 Disassembly 5. Gently pull the two release latches & on the sides of the memory socket in the direction indicated by Figure 5 the arrows (Figure RAM Module 6. The RAM module will pop-up (Figure d), and you can then remove it. Removal (cont’d.) c.

  • Page 34: Removing The Processor

    Disassembly Removing the Processor Figure 6 Processor Removal 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and RAM (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a.
  • Page 35 Disassembly 5. Remove screws from the CPU board. 6. The CPU board will pop-up. 7. Carefully (it may be hot) lift the CPU board up and off the computer (Figure Figure 7 8. Reverse the process to install a new CPU board. Processor Removal 9.

  • Page 36: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and RAM (page 2 - Module Removal 2. Carefully disconnect the cables accordingly and remove screws 3.

  • Page 37: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 9 Bluetooth Module 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5), and hard disk (page 2 - Removal 2. Remove the screw 3. Carefully disconnect cables &...

  • Page 38: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 10 1. Turn off the computer, and turn it over and remove the battery (page 2 - Keyboard Removal 2. Turn to the rear of the computer and lift the hinge cover to release it (you may need to use a small screw- &...
  • Page 39 Disassembly 7. Remove the keyboard plate (Figure Figure 11 8. Disconnect the keyboard ribbon cable from the locking collar socket Keyboard Removal 9. Carefully lift up the keyboard (Figure f) off the computer. (cont’d) e. Remove the keyboard plate and disconnect the cable from the locking collar.
  • Page 40 Disassembly 2 - 16...

  • Page 41: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the R130T series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 42: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts page A - 3 Bottom page A - 4 page A - 5 DVD Super Multi page A - 6 A - 2 Part List Illustration Location...

  • Page 43: Top

    Part Lists Figure A - 1 無鉛 黑色(無鉛) 無鉛 無鉛 無鉛 無鉛 無鉛 (灰色) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top A - 3...

  • Page 44: Bottom

    Part Lists Bottom 無鉛 無鉛 無鉛 無鉛 海華 無鉛 展達 無鉛 無鉛 海華 無鉛 展達 無鉛 (半卡) 無鉛 無鉛 無鉛 Figure A - 2 無鉛 無鉛 Bottom 無鉛 黑色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 北橋 無鉛...

  • Page 45: Lcd

    Part Lists Figure A - 3 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (壓克力) 無鉛 精乘 無鉛 透明 設變虛線 無鉛 LCD A - 5...

  • Page 46: Dvd Super Multi

    Part Lists DVD Super Multi Figure A - 4 DVD Super Multi 無鉛 無鉛 內縮 無鉛 無鉛 (非耐落) 無鉛 A - 6 DVD Super Multi...
  • Page 47 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the R130T notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 48: Schematic Diagrams

    Schematic Diagrams System Block Diagram CLEVO R130T System Block Diagram USB BOARD 1.5VS/1.05VS COM Port. USB Port. 1.8V/0.9V 6 -71-R 1303 -D03 MEMORY TERMINATIONS CLOCK GEN. PROCESSOR CLICK BOARD Int Mic Con. SL G8 SP 51 3V VCORE Penryn-SFF Finger Print Con.

  • Page 49: Hdi Con

    Schematic Diagrams HDI Con 3. 3V S ED GE _C ON N EC TO R 1 To CPU Board VD D 3 3 .3VM 5V S SYS 5V Sheet 2 of 21 3. 3V HDI Con 1.0 5VS 1 .5VS R TC VC C LAN _ DS M# 9 9805 06...

  • Page 50: Kbc-Ite It8513E

    Schematic Diagrams KBC-ITE IT8513E K B C _A V D D L 1 0 H C B 1 00 5 K F -1 21 T 2 0 V D D 3 V D D 3 C 9 1 C 9 6 C 10 7 C 1 0 0 C 7 4...

  • Page 51: Crt Port, Ledi

    Schematic Diagrams CRT Port, LEDI CRT PORT 3. 3V S 9 8050 6 A dd"* " *B A V 9 9 R E C TI F I E R * B A V 9 9 R E C T I F I E R * B A V 9 9 R E C T I F I E R J _ C R T1 ML P 1...

  • Page 52: Lvds & Led Panel Driver

    Schematic Diagrams LVDS & LED Panel Driver 3 . 3 V 3 . 3 V 3 . 3V 3. 3 V S Y S 1 5V S Y S 1 5 V U 1 0 D 74 L V C 0 8 P W U 1 0 A C 9 9 74 L V C 0 8 P W...

  • Page 53: Azalia Codec Amp Alc269Qfn

    Schematic Diagrams Azalia Codec AMP ALC269QFN ALC269 (QFN) 3 . 3 V S 3 . 3V S _ A U D L1 2 F C M1 6 08 K -1 2 1T 0 6 R 6 6 * 0_ 0 4 1 .

  • Page 54: Jmb385 Card Reader

    Schematic Diagrams JMB385 Card Reader JMB385 CARD READER 02/12 3. 3 V S 3 . 3 V S _ C A R D 3 . 3V S _ C A R D R 21 4 *1 5 m i l _ s h or t S D _C D # R 2 2 1 4 .

  • Page 55: New Card, Ccd, Fan

    Schematic Diagrams New Card, CCD, Fan NEW CARD 3 . 3 V 10m il U 1 4 C 140 0 . 1u _16 V _Y 5 V_ 04 7 4A H C 1G 08G W B U F _P LT _R S T# 2 , 3, 7, 9 , 11 B U F _P LT _R S T # 3.

  • Page 56: Pcie Lan Rtl8111Dl, Rj45

    Schematic Diagrams PCIE LAN RTL8111DL, RJ45 RTL8111DL L2 6 LA N _ V D D 3 H C B 16 0 8 K F -1 21 T 2 5 4 0 mil 3. 3 V FO R RTL 8102EL/810 3EL RTL 8102E L/8103EL PV T: Fo r Cl evo N or ma l D es ig n 1 00 MHz /1 00...

  • Page 57: Click, Bt Con., Tpm

    Schematic Diagrams Click, BT Con., TPM CLICK CONN Bluetooth (T/P,F/P,MIC) 5 V S _ T P R 1 33 *2 0 mi l _ sh o rt 5V S R 1 35 * 0_ 0 6 R 1 32 R 1 31 Sheet 10 of 21 10 K _ 0 4 1 0 K _ 04...

  • Page 58: Wlan, 3G, Gps

    Schematic Diagrams WLAN, 3G, GPS GPS POWER C 189 16V? 6.3V MINI-PCIE CARD (WLAN) R 10 4 *0 _ 0 8 3 . 3 V 20 mil GP S _ 3 . 3 V S R 9 9 *5 0 m i l _ sh o rt _ 08 3.

  • Page 59: Hdd, Odd, Usb, G-Sensor

    Schematic Diagrams HDD, ODD, USB, G-Sensor SATA ODD G Sensor J _O D D 2 S A T A _ T XP 1 V D D 3 S A T A _ T XP 1 2 V D D 3 S A T A _ T XN 1 S A T A _ T XN 1 2 R 1 20...

  • Page 60: Com Port, Ext Usb Con

    Schematic Diagrams COM Port, Ext USB Con. CO M POR T R 9 8 *1 0 mi l _s h ort _0 4 C L K _S I O4 8 2 3 . 3 V A V C C L 13 H C B 1 00 5 K F -1 21 T 2 0 3 .

  • Page 61: 5Vs, 3Vs, 3.3Vm, 1.5Vs, Vin1

    Schematic Diagrams 5VS, 3VS, 3.3VM, 1.5VS, VIN1 P D 9 C H 3 5 5 P T V I N 1 S Y S 5 V V D D 3 V I N P D 1 0 PM OS Q 1 0 150m A C H 3 5 5 P T P C 83...

  • Page 62: Power Vdd3/Vdd5

    Schematic Diagrams Power VDD3/VDD5 V I N 1 P R 3 3 1 0 _0 6 P C 3 9 S Y S 5V 0 . 0 1 u _ 50 V _ X 7 R _0 4 LG A T E 1 980506 P C 3 6 P D 4...

  • Page 63: Ac_In, Charge

    Schematic Diagrams AC_In, Charge P R 1 0 * 15 m i l _ s ho rt P Q1 RL- 2550 to ESR3 216 V I N A M4 8 35 P 3.6A 3.6A J_ D C -J A C K 1 P L 1 2D C - G 21 3 -B 4 9 H C B 4 5 32 K -8 0 0_ 1 8...

  • Page 64: Usb+Com Board

    Schematic Diagrams USB+COM Board USB+COM Port Board U V C C U S B 1 U L 1 U V C C U S B 1 _1 H C B 1 0 0 5 K F -1 2 1 T2 0 60 mil U C 2 U C 3...

  • Page 65: Power Button Board

    Schematic Diagrams Power Button Board L_3.3V L_3.3V LID SWITCH 100K_04 *BAV99 RECT IFIER O UT ME268-002H 0.1u_16V_Y5V_04 100p_50V_NPO_04 LGND LG ND LGND PSU 1, PSU 2 LGND Sheet 18 of 21 LLID_SW# Power Button L_3.3V LJ_CO N1 Board LLED_PWR# LLID_SW# LM _BT N# LSW1 88266-05001...

  • Page 66: Click Board

    Schematic Diagrams Click Board C L I C K B O A R D C J_ T P2 C T PBUT TON _L C T P_SCR OL L_D OWN RIGHT C SW1 ~4 LIFT C T P_SCR OL L_U P C T PBUT TON _R C S W 2 CSW1...

  • Page 67: Fingerprint Board

    Schematic Diagrams FingerPrint Board Tot al:4 6 Pcs F 3 . 3 V F 3 . 3 V F C 11 F C 1 0 F J _ F P 1 F L1 H C B 1 00 5 K F -1 2 1 T 20 1 u _ 6 .

  • Page 68: Gps Antenna Board

    Schematic Diagrams GPS Antenna Board Sheet 21 of 21 GJ_ ANT1 GN D1 GN D1 GPS Antenna GN D2 Board GN D2 C197 D91 GN D3 GN D3 GN D4 GN D4 * TN70G-0 10 ? ? ? ? GPS Antenna Con. ? ? ? layout ? ? ? ? ? ? ? ? ? ? B - 22 GPS Antenna Board...
