Quick Start Guide
1
Figure 1 - 14
Rear View
1. Vent/Fan Intake
2. RJ-45 LAN Jack
3. HDMI-Out Port
4. DC-In Jack
5. DisplayPort 1.4,
Over USB 3.2
Gen 2 (Type C)
Port

DisplayPort Cables
When using cables connect-
ed to the Mini DisplayPort,
try to make sure that the ca-
bles are not bent excessive-
ly, as bending the cables
may cause signal problems.
Overheating
To prevent your computer
from overheating make sure
nothing blocks the Vent/Fan
Intake while the computer is
in use.
1 - 22 Rear View - Model B
Rear View - Model B
1
On this computer model there is one USB 3.2 Gen 1 Type A port, One USB 3.2 Gen 2 Type
A port, one USB 3.2 Gen 2 Type C port with Power Delivery DC-In Function and one Dis-
playPort 1.4, Over USB 3.2 Gen 2 Type C port.
Note: The maximum amount of current supplied by the USB ports is 900 mA for USB 3.2 &
Type C.
5
3
4
2

USB Ports
1
