ColorKey MobilePar HEX 5 User Manual page 8

DMX Values
6CH DMX values
CH 1 0-255
CH 2 0-255
CH 3
0-255
CH 4
0-255
CH 5
0-255
CH 6 0-255
10CH DMX values
CH 1 0-255
CH 2 0-255
CH 3 0-255
CH 4 0-255
CH 5 0-255
CH 6 0-255
CH 7 0-255
0-9
CH 8
10-255
0-39
40-79
80-119
CH 9 120-159
160-189
190-219
220-255
CH 10 0-255
MobilePar HEX 5 User Manual – V1
Red (0-100%)
Green (0-100%)
Blue (0-100%)
White (0-100%)
Amber (0-100%)
UV (0-100%)
Master Dimmer (0-100%)
Red (0-100%)
Green (0-100%)
Blue (0-100%)
White (0-100%)
Amber (0-100%)
UV (0-100%)
Open (NA)
Strobe (Slow to Fast)
NA
Auto Program: Jump
Auto Program: Fade
Auto Program: Pulse
Sound Active: Jump
Sound Active: Pulse
Sound Active: Color Strobe
Auto Program speed (Slow – Fast)
8
