Sound Sensitivity
To set the Sound Active sensitivity on the MobilePar HEX 5, follow the
instructions below:
1. Press (Menu) repeatedly to cycle to �� SUB
2. Use (<) or (>) to select desired program
3. Press (Enter) to cycle to �� SPEED
4. Use (<) or (>) to adjust microphone sensitivity from Se1-Se9 (low to high)
5. Press (Enter)
DMX Control
Connecting to a wireless DMX transmitter:
To connect to a wireless DMX controller or other Group ID for control, do the
following:
1. Turn on your wireless DMX transmitter
2. Turn on your MobilePar HEX 5
3. Press (Menu) repeatedly to cycle to Wireless DMX (01-07) setting
4. Use (<) or (>) to select wireless 01-07; (off) is also a setting for no Wireless DMX
5. Press (Menu) to cycle to Master setting
6. Use (<) or (>) to set Master (off)
7. Press (Menu) to cycle to DMX.
a. The DMX address can now be set as needed for programing.
8. Use (<) or (>) to select (Addr)
9. Press (Enter)
10. Use (<) or (>) to select operating Channel Mode, (6ch, 10Ch)
11. Press (Enter)
12. Use (<) or (>) to set DMX Address (d001-d512)
13. Press (Enter)
14. Wi-Fi symbol will blink when connected
