ColorKey MobilePar HEX 5 User Manual page 7

Menu Guide
Mode Display
RF Remote rF
Manual Color COL
Settings R00-R99; G00-G99;
B00-B99; W00-W99;
Y00-Y99; P00-P99
Wireless OFF/01/02/03/04/05/06/07; Red,
Group ID Green, Blue, White, Yellow,
Magenta; Cyan
Master MASTER On/Off
Fixture Set
DMX Mode DMX ADD. 001-512
or Slave
DMX CH. 06/10
Mode
Color Select Color SUB 01-48
Color SPEED 00-09
Color Jump JUMP SPEED 01-09
Fade Mode FADE SUB 01-02
FADE SPEED 01-09
��
Sound Active SUB 01-04
Mode
��
SPEED 01-09
APP APP
MobilePar HEX 5 User Manual – V1
Function
Press "ENTER" to cycle from "MASTER" to
"SLAVE".
"SLAVE" allows for control by RF remote.
"MASTER" mode saves the last state
received from the RF remote, disconnects the
remote, and broadcasts that state to all other
lights in the setup.
"ENTER" to select the color to change. Use (
< or >) to adjust brightness for each value to
create an exact color profile.
2.4G wireless
DMX settings.
Use ( < or >) to change the Group ID from
01-07 or OFF
Use ( < or >) to turn on or turn off. While "On",
the fixtures sends wireless control signal
Use ( < or >) to adjust the DMX address
Use ( < or >) to adjust DMX Channel Mode for
6 channel or 10 channel.
Use ( < or >) to manually select a color
Use ( < or >) to adjust the strobe speed. "00"
is no strobe.
Use ( < or >) to adjust the Jump speed
"01":fade, "02":pulse
Use ( < or >) to adjust the fade speed
Four sound active modes are available. The
light will follow the rhythm of the music.
Mode1: Color Jump; Mode 2: Fade off; Mode
3: Normal color strobe; 4: Light color strobe
Use ( < or >) to adjust the microphone
sensitivity
APP mode. While using your mobile phone.
Press "ENTER" to see Wi-Fi ID "LED-XXX"
7
