The RESOLVEX™ M10 96 is typically shipped with the following items:

296-7501 RESOLVEX™ M10 96

278-2036 Operation Manual

279-0010 Installation Kit

278-0035 System 96 Column Seal, Removable Adhesive (6 month shelf life)

278-0021 96 Deep Well Collection Plate, 1.2mL x 96-Well

278-0020 96-Well x 2mL Collection Plate

278-0300 Single Well Plate, 96 Well Reservoir, No Dividers 300mL Volume
The RESOLVEX™ M10 96 XT (Extra Tall) Option is typically shipped with the following items:

288-0006 RESOLVEX™ M10 96 XT

278-2036 Operation Manual

279-0010 Installation Kit

278-0035 System 96 Column Seal, Removable Adhesive (6 month shelf life)

278-0012 1.2 mL x 96 Well Collection Tray

278-0020 96-Well x 2mL Collection Plate

278-0030 Single Well Plate, 96 Well Reservoir, No Dividers 300mL Volume

278-0302 96-Well Reservoir Waste Tray
6 Installing the
The RESOLVEX™ M10 96 does not include a filter on the gas supply input. A clean, oil-free gas
source must be used to prevent the unit's pneumatics and sample contamination.
Slight movement of the manifold may occur as the unit is pressurized when connecting the gas
supply.
1. Open the unit box and remove the accessories boxes. Standard contents are listed
above.
2. Remove the unit from the box and place in desired location. See the Site Requirements
in previous page.
Plumb the unit into the gas source by using the provided tubing in the Installation Kit and inserting
one end of the tubing into the open port at the rear of the unit and the other end into the supplied
gas source. Gas requirements are mentioned in the previous page.
