Power LED (green) Lights when the power is on. It also reports error conditions
Busy LED (green)
The Power and Busy LEDs are used to indicate that an error has
occurred with the DAT Autochanger. Refer to Chapter 5,
Troubleshooting and Diagnostics for descriptions of the error
codes displayed by the Power and Busy LEDs.
Locked LED
(green)
The DAT Autochanger uses the LOAD function to detect
reversed cassettes or the absence of a cassette.
LOAD
UNLOAD
Never attempt to remove a magazine unless it is in the unload
position. You may damage the pick arm.
(through a blinking sequence).
Lights whenever the drive is active. It also reports error
conditions (through a blinking sequence in conjunction with
the Power LED).
Note
Lights whenever the LOAD and UNLOAD buttons are
disabled. This occurs when a cassette is in the drive, or if
commanded from the system software. This LED blinks
when an unload operation is pending in sequential access
mode.
Note
Pressing this button initiates a load magazine sequence
DAT Autochanger will check the cassettes in the magazine
(making note of empty spaces) and that all cassettes present
can be inserted in the drive correctly.
Press this button to initiate an unload sequence
Autochanger will return the magazine to the unload position.
Caution
Equipment Description
the
the DAT
19
