Polycom RSS 2000 User's Guide
For MCU single point recording, the generated file is named in the format of conference_name + start_time,
where the conference_name is set on the MCU. For example, if a conference on the MCU that is named as
RECORDING_TEST and starts recording at 8:43:47 on April 19, 2006, the file generated will have a name of
RECORDING_TEST_APR19_2006_084347.

Point to Point Recording

To make a point to point recording, you should firstly use the web client on the RSS 2000 to initiate a point to
point conference and set the conference parameters. The number of conferences is 2 by default and can be set up
to 4. Then you call from two endpoints or MCUs into the conference. When only a single endpoint enters the
conference and starts recording, you can see a single-window screen at the endpoint showing the loopback image
of that endpoint itself. And when both the endpoints enter the conference, you can see a two-window screen at
either of the endpoints, which is programmed by the RSS 2000, with each window showing the image of one of
the two endpoints.

Start Recording through Menu Interface

Call from an endpoint to connect to the RSS 2000 and enter the main menu, and use the controller to select Point
to point Recording, and then you will see the current conference established on the RSS 2000, as shown in Figure
2-10.
Figure 2-10 Conference Room
17
