VII.3.3 GPIO port
DB9F connector.
2 ground contact inputs.
2 NA/NC relay outputs.
-Max voltage: 125VAC (0.5A), 110VDC (0.3A), 30VDC (1A).
-Max. current: 2A.
VII.3.4 RS232 port
Sub-D 9 ways Female connector.
VII.4 Power supply.
Universal Input Range.
AC input range: 100-240 V.
Frequency range: 50-60 Hz.
Output Power: 30W (with battery in charge status).
Optional battery.
VII.5 Weight and dimensions
Height: 70 mm; Width: 285 mm.; Depth: 243 mm.
Weight: 2 Kg.
