V.5.2.9. Screen 9: GPIO and Serial Port bit rate
This represents the GPIO status and serial ports bitrate:
G P I : 0 0 P A : 9 6 0 0
G P O : 1 0
V.5.3 The BOOK Key
This key directly accesses the internal Address Book. By pressing this key we can
view and connect to entries in the Address Book. (Note that to edit or modify
entries the user has to go into the BOOK option in the main menu).
Pressing BOOK the user can enter the Address Book index:
< <
Using the left and right navigation keys the user can go through the different
entries in the Address Book index. By pressing OK we select the item that is on-
screen. Now the screen shows the number/numbers to call, or the IP address,
depending on which has been saved.
L 1 : 1 2 3 4 5 6 7 8 9 0
L 2 : 1 2 3 4 5 6 7 8 9 0
Pressing OK again will process this information, that is, PortaNet will configure
the Encoder according to the BOOK entry and make the connection over ISDN or
IP. However, if you press the right arrow instead you can simply display the
encoding mode saved.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
B O O K [ 0 1 ]
