Auxiliary data:

port with 2 inputs and 2 outputs. The auxiliary data can be
sent/received along with the audio for remote control/signalling.
Control and monitoring:
panel and from its embedded web page. All the controls are
configurable remotely. The keypad can be controlled and also blocked
from the web page for security reasons.
Small and lightweight:
dimensions are: 70 x 285 x 243 mm.
I.1 The set of Manuals
The Prodys IP Family User Manual
provided by the Prodys IP Family of codecs.
For some specific features or restrictions, the user is referred to the proper
Hardware and Reference Manual
requirements, physical and electrical parameters are also included in this
document.
Hardware and Reference Manuals are available for:
ProntoNet
ProntoNet LC
ProntoNet IP Decoder
Nereus
Nereus One
PortaNet
Nomada IP
If several Prodys IP Family codecs are managed by means of the ProdysControl
application please refer to the
A wired control interfaces is provided (RS232) for most of the codecs. This
control interface is useful if a specific customer management software is in place.
For detailed description please refer to the
Manual.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
PortaNet includes a serial port (RS232) and a GPIO
The unit can be configured from its front
its weight is about 2 kilograms and its
is applicable to most of the common features
applicable to the codec in use. Installation
ProdysControl Manual
Prodys IP Family codec SDK User's
sales@prodys.net
Page 8
as well.
