IDLE: The line is detected physically but no connection is being made. The
display shows IDLE and the disconnection code:
Tx CONNECTED:
"Connected.
Rx CONNECTED:
"Connected" and the Decoder status:
CALLING: In the process of making a connection. The display shows an arrow
indicating outgoing calling and the ISDN number or IP address:
When PortaNet is configured to IP Multi-Unicast, the format of the
messages will be the following:
DOWN: The communication line is not physically detected. Most likely the
interface is not plugged in. The Display shows "DOWN":
IDLE: The line is detected physically but no connection is being made. The
display shows IDLE and the disconnection code:
Tx CONNECTED: One or more of the different Unicast connections which are
available is connected.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
TX:IDLE(0)
RX:IDLE (0)
The Tx part of the line is connected. The display shows
TX->CONNECTED
RX:CONNECTED
The Rx part of the line is connected. The display shows
TX:IDLE(0)
RX:CONNECTED
TX 1234567890
RX:IDLE(4)
TX:_ _ _ _ _ _ _ _ _ _ _
RX:DOWN
TX:_ _ _ _ _ _ _ _ _ _ _
RX:IDLE (4)
TX:_ _ □ _ _ _ _ □_ _ _ _
RX:IDLE (4)
Page 41
