ETHERNET PORT

This option allows the user to set the speed and duplex settings for the ethernet
port.
{ a u t o } 1 0 H D 1 0 F D 1 0 0 H D 1 0 0 F D
NOTE: When the unit is connected to a device which does not support auto-
negotiation, and it is set to work in a fixed mode, the Ethernet interface must be
configured to match the configuration of that device, so 'Auto' should not be
selected in this case.
PORTS
This option allows the user to set the web server port, and the base port of the
TCP/UDP port group used for audio, data and control.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
O
K
S E T I N T A D D R E S S
. . .
E T H C O N F
P O R T S C O N F
{ W E B } B A S E
O
K
S E T B A S E P O R T
5 0 0 1 1 _
