Each connection is represented by a small square.
Rx CONNECTED:
"Connected" and the Decoder status:
Line 2 is not available when the init is configured in IP Multi-Unicast.
V.5 Control Keys
V.5.1 The CALL 1 and CALL 2 keys
The fundamental role of these keys is the initiation and termination of a
connection. Note that the keys have different functions depending on the
communication line status at any given moment. Additionally, the display will
also show different information depending on the type of NET selected – IP or
ISDN.
Depending on the line's status,
way:
With the line disconnected:
a) Initiation of a communication: Pressing
access the call initiation menu. Depending on the type of NET
selected (IP, ISDN) the dialog that you will see will vary. (Note
that, CALL 2 only works when PortaNet works as a DUAL codec
b) Connecting to an incoming call: if the PortaNet is pre-configured
to manual answering, the
line when an incoming call is detected on the respective lines.
With a line connected: There are two different functions:
a) A short press will display on-screen the number or IP address of
the current connection.
b) A long press (over 1 second) will disconnect the associated line.
It is posible to program a number of call retries from the PortaNet web page.
With either the Tx or Rx part connected: There are two different
functions:
4
DUAL codec: PortaNet is able to operate as a DUAL codec over ISDN and over IP (when
configured in 'DOUBLE' mode).
