The Decoder status information only appears if the line is connected
If the line is showing an IDLE status, an indicator code will show the cause of the
last disconnection.
L 1 : I D L E
L 2 : N O T
When the lines are not connected the selected NET will be shown.
L 1 : I D L E
L 2 : N O T
When the PortaNet is operating as a DUAL codec, there will be two independent
Decoders, one for each line. In all other cases information will only show on the first
line of the display as there will be only one Decoder working (even if there are two
communication lines connected).
L 1 : I D L E
L 2 : N O T
When the lines are connected the direction of the arrow will indicate if the unit made
or received the connection.
L 1
L 2 :
The backup can be in one of the following states:
DISABLED: The display doesn't show any information about it.
BKUP OFF: The backup is enabled but not activated, that is, the main line is
working appropriately.
TDWN: The main line is dropped and the display shows the countdown of the
timer.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
( 0 )
A V A I L A B L E
( 0 )
A V A I L A B L E
( 0 )
A V A I L A B L E
C O N N E C T E D F R A M E D
N O T A V A I L A B L E
L1:CONNECTED FRAMED
L2:--- BKUP OFF
L1:CONNECTED SEARCH
L2:--- TDWN=20
