VI.2 Main Menu
The main menu has the following options:
NET: This allows us to select the communications port required.
ENC: Here you can configure Encoders 1 and 2.
CONF: Here you can configure various general parameters of the unit, for
instance selecting the audio input or setting up the LAN port.
INF: From here you can obtain information on the software version and
various configuration parameters of the ISDN port.
VI.3 NET: Selecting a communications port
The PortaNet has three different communication ports that allow the unit to
operate over three distinct types of network: IP, ISDN and dedicated digital
networks (X21 port).
{ I P } I S D N
The NET option is only available if the lines are not already connected. If they
are busy, the display will show the following text:
Each NET type selection will of course have their own set of configuration
parameters, as will be seen next.
When selecting IP, a new screen will prompt the user for the type of IP
codec: Unicast/Multicast or Multi-Unicast, and for the type of protocol
to use: Prodys VX, SIP/SAP, RTP...
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
M A I N M E N U
{ N E T } E N C C O N F I N F
N E T S E L E C T I O N
N O T A V A I L A B L E
L I N E C O N N E C T E D
