CNUM: An abbreviation for 'Calling Number'. This option allows you to program
up to a maximum of three numbers that will work as incoming call filters. When
the CNUM option is activated, the PortaNet will respond automatically only to
calls made from these CNUM numbers.
separately.
SPID: When you are using NAT1 or DMS100 you must enter the correct Service
Profile ID (SPID) numbers for the ISDN BRI circuit.
Automatic or manual response: When automatic response is selected, the
unit will connect automatically to an incoming call, always doing so when there is
no restriction imposed by the local number or other such call filters. In manual
mode, the incoming calls are indicated on-screen and the user simply presses the
corresponding CALL key to go ahead and connect that line.
9
LOOP : It is possible to enable an external loop on any of the two B channels of
the ISDN interface. By enabling this external loop, all the incoming data on that
channel will be sent back without any processing.
The ISDN parameter configuration screens are as follows:
LNUM:
L I N E 1 L O C A L N U M B E R
-
CNUM
L I N E 1 C N U M M O D E
{ O N } O F F
{ N 1 } N 2 N 3
9
This option is available from version 5.2.1 onwards.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
It is possible to program each line
O
K
L I N E 1 C N U M S
O
K
