IDLE: The line is detected physically but no connection is being made. The
display shows IDLE and the disconnection code:
CONNECTED: The line is connected. The display shows "Connected" and the
Decoder status:
3
CALLING : In the process of making a connection. The display shows an
arrow indicating outgoing calling and the ISDN number or IP address:
4
RING : Receiving a call on the line. The display shows an arrow indicating
incoming calling and the ISDN number or IP address:
The Decoder can be in one of the following states:
FRAMED: Audio Synchronised. The displays shows the word "FRAMED":
SEARCH Searching for synchronisation. The displays shows the word
"SEARCH":
3
This status is not available on X21, so these messages apply only to ISDN and IP connections.
Prodys S.L. Tel: +34 91 6896880 Θ Fax: +34 91 6943777 Θ Email:
L1:DOWN ISDN
L2:DOWN
L1:IDLE (0) ISDN
L2:IDLE (0)
L1:CONNECTED FRAMED
L2:DOWN
L1: 1234567890
L2:DOWN
L1: 1234567890
L2:DOWN
L1:CONNECTED FRAMED
L2:DOWN
L1:CONNECTED SEARCH
L2:DOWN
