1. Battery Information.
2. Audio input VU meters.
3. Audio output VU meters.
4. Decoding algorithm.
5. Encoding algorithm.
6. IP configuration parameters.
7. Net configuration: NET type selected (IP, ISDN o X21), protocol...
8. Audio Input Configuration.
9. GPIO status and Serial Port bit rate.
V.5.2.1. Screen 1: Battery information
This information will vary depending on the connection status of the battery. If
the battery is not connected to the unit, this screen will show the following text:
B A T T E R Y N O T P R E S E N T
If the battery is connected, this screen will show information about the charge of
the battery:
B A T T E R Y : 6 0 %
█ █ █ █ █ █ █ █ █ ▌
V.5.2.2. Screen 2: Audio input VU meters
The audio input levels are represented on-screen horizontally over 18 characters.
Each character represents 3dB. All characters showing will represent 0 dBFs.
When only one character is showing it therefore represents a value between –96
and –56 dBFs. The dBFs value is indicated on the right of the LCD screen. The
input is indicated by a < symbol following the L and R characters.
L : > > > > > >
R : > > > > >
