Preface

Manual Contents

This manual contains the information necessary to operate the Shuttle.
The information in this manual is for operators.
Study and understand this information thoroughly before you operate the machine.
Failure to do so could result in damage to equipment or personal injury (see chapter
Safety). Please consult your local Lely service provider if you do not understand the
information in this manual, or if you need additional information. Store this manual in
a safe place for future reference.
All information in this manual has been compiled with care. Lely shall not be liable for errors or faults in
this manual. The recommendations are meant to serve as guidelines. All instructions, pictures and
specifications in this manual are based on the latest information that was available at the time of
publication. Your machine may comprise improvements, features or options that are not covered in this
manual.
Applicability
The table below shows the type numbers of the milking robot for which this manual is applicable.
Model
Shuttle sampling device
Standard Torque Loading of Parts
All the nuts, bolts and screws used on the machine are torque tightened to standard torque loadings
applicable to the construction materials used.
If a part has a non-standard torque loading, it is specified in the applicable part of the manual.
Registration
The type and serial number plate is mounted at the left rear (below the cover) of the sampling device.
Always include the type and serial number of your product, when you contact your local Lely service
provider or when you order spare parts.
Figure 1. Type and serial number plate
Preface
in n o vato rs in ag ric u ltu re
Type number
5.1501.0020.1
7
