AJAX LightSwitch Jeweller User Manual page 21

4. Select LightSwitch in the list.
Parameter
Malfunction
Jeweller Signal Strength
Connection via Jeweller
Name of the button/buttons
Operating time
Lock Switch Buttons
Meaning
Clicking on opens a list of switch
malfunctions.
The eld is displayed only if a malfunction is
detected.
Signal strength between the switch and the hub
(or the range extender) via the Jeweller channel.
Recommended values: 2–3 bars.
Jeweller is a protocol for transmitting
LightSwitch events and commands.
Learn more
Connection status between the switch and the
hub (or range extender):
Online — the switch is connected to the hub
(or range extender).
O ine — the switch has lost connection
with the hub (or range extender).
the device
.
The section that shows the state of the switch
buttons:
On — the switch is on, and the light is on.
Off — the switch is off, and the light is off.
The time during which lighting will be switched
on. The eld is displayed when the device is
operating in pulse mode (the Shutoff by Timer
option is activated).
The switch button lock status is displayed as
follows:
Check
